barbell type tanker rail hose

1. connecting aft manifold and tail hose

2. lifting lugs should be able to sustain loads, minimum breaking load is 12”=100KN 16”=150KN 20”=200KN

3. rated working pressure: 21 bar

4. minimum reserve buoyance: 20% or according to customer requirements

5. electrical continuity: electrical continuous or discontinuous

6. leak detection system: after the failure of the primary carcass, the detector will react to the leakage to remind the operator to remove the damaged hose to avoid economic loss and environmental pollution.

7.cover: PU or rubber

Specifications can be designed by customer requirements.
